All In One Supply Solar Energy Storage System 5000w Off Grid Home Solar System Kit
USD 2300-2700

MODEL : SP-5KW

LEAD TIME : 7-15days

PRODUCT ORIGIN : CHINA

SHIPPING PORT : GUANGZHOU/FOSHAN

PAYMENT : 30% deposit by T/T , 70% balance by T/T before shipment

Whatapp:+86 13690853732

Email: candy@sunchees.com

Description Specification Downloads

Off Grid Solar With Generator system

SUNCHEES Can Provide What Service To Your ?

1:Professional R&D Team

We have 12+ years professional R&D team to provide customers best design , professional install/ test guide and after sale sevice, sunchees products are successfully sold to more than 130 countries,Won five-star praise from 100% customers

2:OEM/ODM Service

Sunchees can offer OEM service as per your specific requirements ,Customize the solar system and solar air conditioner solutions in the practical application ,Three new products lead the market every year.

3:Perfect after-sales service system

Once the order is confirmed, we will arrange production immediately. Powerful productivity and automation.Can promise delivery in the short term. Such as:Sampleorder(1set-10set)delivery time:5-7 workday , Bulk order:(20-100set) delivery time: 10-20 workdays.

Regardless of the size of the contract, we will strictly implement the provisions stipulated in the contract as scheduled with high quality and quantity; If we can't deliver on time, we will pay 5% of the total amount as liquidated damages to your company;

2. In the process of production, we will arrange a special person to feedback the production progress of the goods regularly;

3. We will pay a return visit to the implementation of each contract, to ensure that the goods timely arrives in the hands of customers.

How does the off grid solar power system work:

This system not only has solar power system function,but also has city grid complement function and UPS function
At daytime,the solar panels will generate the electricity to charge the battery bank through solar charge controller and the inverter will convert battery DC power into AC power and take the loads.
At nighttime,with fully charged battery bank,the inverter will convert battery DC power into AC power and take the loads
When there is no sunshine and battery power is used out,the inverter will automatically switch to use city grid power and take the loads

Advantage:

  • 100% green energy,no pollution,no noise
  • High efficiency solar panel with 25 years lifespan can guarantee fast cost-recovery and long-term benefit
  • Stand-alone system,easy installation and operation
  • Nice after-sale service,provide installation guide and technical support

Our campany:

Complete Off Grid Solar

Warranty policy:

  • Solar panel has 10 years warranty,during warranty if any quality problem,we will ship new one for replacement.
  • lithium  battery has 3 years warranty,during warranty if any quality problem,we will ship new one for replacement.Quality problem means acid leakage or irregular shape.
  • Inverter,charge controller,and PV combiner have 2 years warranty,during warranty if any quality problem,we will ship free PCB for replacement

solar system wholesale adventagesolar system wholesale contact us

Parameter Name Parameter Value
Solar Panel - Max power 600W
Solar Panel - Solar Cell Monocrystalline
Solar Panel - Maximum Power Current (IMP) 13.90A
Solar Panel - Output Tolerance ±3%
Solar Panel - MaximumPowerVoltage(VMP) 39.18V
Solar Panel - Open Circuit Voltage(VOC) 47.40V
Solar Panel - Short Circuit Current(ISC) 14.01A
Solar Panel - Temperate coefficient of Isc  0.05%/℃
Solar Panel - Frame Aluminum alloy frame
Solar Panel - Temperature range -40℃~ +85℃
Solar Panel - Product Dimension 2115 * 1052 *40 mm
Solar Panel - Weight 20.5 kg
Solar Panel - Certificates TUV、IEC,CE
Solar Panel - Warranty 25Years
All In One Solar Generator - Battery Capacity 200AH
All In One Solar Generator - Rated power 5000W
All In One Solar Generator - Rated voltage 51.2VDC
All In One Solar Generator - Input Frequency 45-65Hz
All In One Solar Generator - Output Wave form Pure Sine Wave
All In One Solar Generator - AC input voltage range 170-275VAC
All In One Solar Generator - Battery voltage range 10.5-15VDC
All In One Solar Generator - Output voltage range 220VAC-240VAC;±5%
All In One Solar Generator - Solar MPPT Voltage Range 72V~150VDC
All In One Solar Generator - Maximum PV Power 3600W
All In One Solar Generator - Floating charge voltage 55VDC
All In One Solar Generator - Maximum efficiency ≥99%
All In One Solar Generator - Product size 662*484*1060mm
PV combiner-PV array input numbers 4
PV combiner-Max single PV array current 10A
PV combiner-Single PV array fuse 10A
PV combiner-Output numbers 1
PV combiner-Max output current 40A
PV combiner-Reference weight (N.W/G.W) 5.3/9.3
PV combiner-Machine size (D X W X H) 340*300*140mm
PV combiner-Packaging size (D X W X H) 450*420*245mm
PV combiner-Ground wire size ≥6mm2
PV Cables - Rated Voltage DC:1.8kv ACU./U:0.6/1kv
PV Cables -Cross Section 4mm2
PV Cables -Color Red /Black
PV Cables -Application Solar panel, inverter, combiner box, PV power station
PV Cables -Rated current 55A
PV Cables -Number of cores NO
PV Cables -conductor copper wire structure NO./mm 56 /0.3
PV Cables -Conductor stranded outside diameter 2.58mm
PV Cables -Test voltage kV / min 6.5/5 No breakdown
PV Cables -Operating voltage AC / DC (KV) 0.6 ~ 1.0/1.8
PV Cables -conductor resistance (20 °C) 40~+90°C
PV Cables -Conductor ≤4.75Ω / km
PV Cables -Maximum operating temperature 120 ℃
PV Cables -Working environment temperature °C -40 ~ +90
