Solar Panel System on grid 10KW Grid Tied Home Solar Power System 10 KW Solar Energy Systems

MODEL : SP-10KW

SYSTEM TYPE : On-Grid Solar System

PRODUCT ORIGIN : CHINA

SHIPPING : Support Express · Sea freight · Land freight · Air freight

PAYMENT : 30% deposit by T/T , 70% balance by T/T before shipment

Whatapp:+86 13690853732

Produt Details

10KW on grid solar system configuration:

                      On grid solar power supply system Model: SPB10KW
System Basic Information

Solar panel rated output power:10KW

Suitable for daily power consumption : <64KWH

 Mono                        Poly Solar panel               type: SP500W Half Cell mono
Max power :500W / Vmp:40.5V  Voc:48.7V Solar Cell Use  Half Cell
Imp 12.34A    Size : 2176*1098*40mm
25 years life time  (CE TUV)
Terminal block: IP65 with MC4 connector
Total : 20PCS
Model  PC4 Multiple PV strings inputs
Simplify wiring between PV array and controller, protections to controller ,features:
Wide range of DC input voltage ;Reliable thunderstorm& surge protection
solar on grid inverter
Power capacity:HBF10KW  MPPT range: Vpv(380V-800VDC)

Maximum-Power-Of-Solar-Module-Array(KWp:56)
Maximum Input Current Of Array:60-137.5A ;Maximum-Open-Circuit-Voltage-Of Array:600VDC
Allowed Voltage Range Of Grid:400V AC
Total : 1 Set
Slope Rooftop or Flat rooftop including complete fittings
wind load:55m/s,snow load:1.5kn/m2  structure:Anodized Aluminum+stainless steel, Angle adjustable
Total : 1 Set
4mm2 PV cable *100M ;10mm2 inverter cablre *50M MC4(4mm2 PV cable each string connect to PV combiner)

How does the off grid solar power system work:

  • This system not only has solar power system function,but also has city grid complement function and UPS function
  • At daytime,the solar panels will generate the electricity to charge the battery bank through solar charge controller and the inverter will convert battery DC power into AC power and take the loads.
  • At nighttime,with fully charged battery bank,the inverter will convert battery DC power into AC power and take the loads
  • When there is no sunshine and battery power is used out,the inverter will automatically switch to use city grid power and take the loads

Advantage:

  • 100%green energy,no pollution,no noise
  • High efficiency solar panel with 25 years lifespan can guarantee fast cost-recovery and long-term benefit
  • Stand-alone system,easy installation and operation
  • Nice after-sale service,provide installation guide and technical support

Packing details:

  • Solar panels are packed in carton and pallet
  • PV combiners and inverter are packed in wooden box
  • Solar charge controller,gel battery,and cables are packed in carton
  • Solar panel racks are in cartons and bulk packing​

Our Factory:

Solar System Case:

Warranty policy:

  • Solar panel has 10 years warranty,during warranty if any quality problem,we will ship new one for replacement.
  • lithium  battery has 3 years warranty,during warranty if any quality problem,we will ship new one for replacement.Quality problem means acid leakage or irregular shape.
  • Inverter,charge controller,and PV combiner have 2 years warranty,during warranty if any quality problem,we will ship free PCB for replacement
