300w Solar Wind Power Generator System Residential Wind Solar Hybrid System
300w Solar Wind Power Generator System Residential Wind Solar Hybrid System
300w Solar Wind Power Generator System Residential Wind Solar Hybrid System
300w Solar Wind Power Generator System Residential Wind Solar Hybrid System

300w Solar Wind Power Generator System Residential Wind Solar Hybrid System

300w Rooftop Solar And Wind Turbine 300w 220v Wind Generator

MODEL : WSP-300W

LEAD TIME : 7-15days

PRODUCT ORIGIN : CHINA

SHIPPING PORT : GUANGZHOU/FOSHAN

PAYMENT : 30% deposit by T/T , 70% balance by T/T before shipment

Whatapp:+86 13690853732

Email: candy@sunchees.com

Product Details

300W off grid solar & wind hybrid power system configuration:

SUNCHEES Off grid wind power systems-WTS300
System Basic Information Wind generator power: 300W; daily average energy:1440Wh
Supply power for lighting/fan/TV

Wind generator Wind generator

Wind generator

Model WT300
Rated power 300W
Starting wind speed 2m/s
Working wind speed 3m/s
Rated wind speed 12m/s
Security wind speed 40m/s
Rated    DC voltage 12V/24V(optional)
Rated rotate speed 900 r/m
Rotor diameter 1140mm
Protection Electromagnetic torque control
and electricity brake
Type 3phases permanent
magnetism generator
Blade material Extra-strong and tenacious
engineering plastics
Packing material Carton box and foam material
Packing dimension 1110*580*240 mm
Wind turbine main
body weigt
7/10.5 kg

Wind controller

Wind controller

WC300w/12v wind charger controller Rated Battery Voltage: 12V
Wind Turbine Maximum Input: 40A
Unload Voltage(factory default): 14V Unload Current(factory default): 25A

Solar Wind Power Generator System

Gel Battery

Capacity:12V/200AH full sealed Solar power Gel battery, Service life:6-8 years ,
Size: 522*240*219mm weight:56KG

Off-Grid inverter

Off-Grid inverter

Pure sine wave inverter Model: SI300w
DC input: 12V
AC output: 110/120/220/230/240V
With  grid  charger  build-in,  protection  against  overload,  short  circuit, anti-reverse, discharger, etc.

Guy cable tower

Guy cable tower

3.6m tower;
It help fasten wind generator in safe altitude.
Use steel material with rust prevention. Easy to install

Cable

Cable

1)2pcs 16mm2*1M battery cable connect

2)4mm2 cable 100M
3)battery terminals

Remark: Refrigerator,air conditioner &water pump is inductive load ,start working power is 3-6 times more than normal power ,in the process of use ,turn on the inductive load first

How does the system work:

  • When there is sunshine and wind, the solar panels and wind turbine will generate power and stock in the battery bank,then inverter will convert the battery DC power to AC power and take the loads
  • When there is no sunshine,no wind and battery power is used out, the inverter will automatically switch to use city electricity to take the loads

Advantage:
Compare to only solar or only wind power system,solar&wind hybrid system can generate and supply power more stably

Wind system case:

Project buyer ShowProject buyer Show

Our factory:

Corporate environment

Packing details:

  • Solar panels are packed in carton and pallet
  • Wind turbine is packed in wooden box
  • Hybrid charge controller,inverter,gel battery,and cables are packed in carton
  • Solar panel racks and wind turbine pole are in cartons and bulk packing

solar system package

Warranty policy:

  • Solar panel has 10 years warranty,during warranty if any quality problem,we will ship new one for replacement.
  • Gel battery has 2 years warranty,during warranty if any quality problem,we will ship new one for replacement.Quality problem means acid leakage or irregular shape.
  • Wind turbine,inverter,charge controller have 2 years warranty,during warranty if any quality problem,we will ship free PCB for replacement.
