YouTube Video:

100kW Off-Grid Solar Power System Installation & Demo #solarenergy #offgrid #lithiumbattery

Product Overview:

The 100kW off-grid solar power system is a robust and cost-effective renewable energy solution designed for large-scale energy demands. Perfect for commercial facilities, factories, or large homes, this system includes high-efficiency 600W Longi Mono PERC solar panels, a powerful 100kW three-phase inverter, and a 360V/300Ah LiFePO4 lithium battery bank.

100kW off-grid solar power system advantage

No grid dependency

All-weather power generation

Say goodbye to power outages and high energy bills

Installation Footprint:

Item	Quantity	Installation Area
Solar Panels	160 pcs	448㎡ (4820 sqft)
Solar Inverter	1 pc	4㎡ (43 sqft)
Lithium Battery	1 set	6㎡ (65 sqft)
Total Area	–	~458㎡ (~4928 sqft)

Kit Configuration:

Component	Specification	Quantity
Solar Panels	600W Longi Mono PERC	160 pcs (96kW)
PV Combiner	PC10-384V, Multi-String Inputs	2 sets
MPPT Charge Controller	384V MPPT, High Tracking Efficiency	4 pcs
Inverter	TI100K, 100KW 3-Phase, 384V DC, 220V/380V AC	1 pc
Lithium Battery Pack	360V / 300Ah LiFePO4 (108kWh)	1 set
Mounting Support	Anti-corrosion Aluminum (Ground/Slope/Flat Roof)	160 sets
Cables & Accessories	6mm² PV Cable 200M, MC4 Connectors, Battery Cables	Customized

Component Specifications:

600W Longi Mono PERC Solar Panel

Cell Type: Monocrystalline Half Cell
Output: 600W per module
Efficiency: ≥21.5%
Dimensions: 2279 × 1134 × 30mm
Lifespan: 25+ years
Warranty: 10 years

360V / 300Ah LiFePO4 Lithium Battery Pack

Total Capacity: 108kWh
Depth of Discharge: 95%
Cycle Life: >6000 cycles
Features: Built-in BMS, scalable design
Warranty: 10 years

TI100K Three-Phase Inverter

Rated Power: 100,000W
PV Voltage Range: 500–800VDC
AC Output: 220V/380V, 3 Phase 4 Wire + Ground
Charger Efficiency: 95%
Product Size: 1200 × 900 × 1820mm
Warranty: 2 years

PV Combiner Box

Model: PC10-384V
Features: Multi-string inputs, surge protection, simplified wiring

100kw Solar Energy System Certificate

Company profile

Sunchees was founded in 2008, head office and factory is located in Foshan, Guangdong. China,but its sales network has spread to more than 100 countries and regions around the world.

sunchee solar system showroom and office

Main business: solar power system one stop solutions, solar inverter , solar air conditioner system, solar street light system . solar DC power system ect .

600w solar panel factory

Sunchees products are widely used in home, agriculture, industry, finance, electric power, transportation, security, new energy. Its stable and excellent performance have been widely recognized.

Solar Inverter Lithium Battery Factory Pictures
