We assemble, wire, and test all the parts necessary to run your off-grid system right in our warehouse. Our designers are pros at building flexible systems that can be expanded if your energy needs change down the road.
all acceptable pure sine wave inverter and a UPS fuction .
Remote monitoring is Auail-able by Using WIFI monitoring kit.
Lithium battery
Nominal voltage : 96V
Nominal Capacity : 260AH
Weight:150KG size:775*515*965mm
Cycles time: 6000 Life time : 10 years
Main Disconnect Box
DC Disconnect
AC Disconnect
Battery Disconnect
PV Combiner
Flexible Inputs Optional
IP65 Protection Degree
DC Cable & MC4 Connect & YBranch
Cross Section:4mm2,6mm2 Optional
Rated Voltage:600VDC(UL)/1000-VDC(TUV)
Rated Current:55A,70A
Colors:Black For STD,Red Optional.
Lifetimes:≤25 years
PV Mounting System
Mounting Rail & Rail Splice Kit:
Al6005 & SUS304 Bolt. Mid & End Clamps:35,40,45,50mm
L Foot Asphalt Shingle Moount & Hanger Bolt Optional
Cable Clip & Tie Optional
Ground Clip & Lugs Optional
10KW solar system load reference:
10Kw Solar home System
Load Name
Load'S Watt
Qty
Total Watt
Lights
11w
20
220w
Fan
80w
4
320w
Computer(LCD display)
150w
2
300w
Printer
250w
1
250w
Fax Machine
150w
1
150w
Refrigerator
120w
2
240w
Washing Machine
300w
1
300w
Microwave
1500w
1
1500w
Electric Cooker
300w
1
300w
Air Conditioner(1HP)
750w
4
3000w
Satellite Tv Receiver/Vcd
25w
1
25w
Color Tv(32 inch)
150w
2
300w
Water Pump
200w
1
200w
Total
7105w
Remark: Refrigerator,air conditioner &water pump is inductive load ,start working power is 3-6 times more than normal power ,in the process of use ,turn on the inductive load first
How does the off grid solar power system work:
This system not only has solar power system function,but also has city grid complement function and UPS function
At daytime,the solar panels will generate the electricity to charge the battery bank through solar charge controller and the inverter will convert battery DC power into AC power and take the loads.
At nighttime,with fully charged battery bank,the inverter will convert battery DC power into AC power and take the loads
When there is no sunshine and battery power is used out,the inverter will automatically switch to use city grid power and take the loads
Advantage:
100%green energy,no pollution,no noise
High efficiency solar panel with 25 years lifespan can guarantee fast cost-recovery and long-term benefit
Stand-alone system,easy installation and operation
Nice after-sale service,provide installation guide and technical support
Packing details:
Solar panels are packed in carton and pallet
PV combiners and inverter are packed in wooden box
Solar charge controller,gel battery,and cables are packed in carton
Solar panel racks are in cartons and bulk packing
Solar Photovoltaic System case:
